Product Details:
|
| Type: | TV Wall Controller | Material: | Metal Case + Toughened Glass Panel,Metal |
|---|---|---|---|
| Name: | 1.8mm Bezel 1 In 10 Out 1x10 2x5 4K Video Wall Controller For LCD Screen | Output: | 9ch And 10ch HDMI |
| Bezel: | 1.8mm | Warranty Time: | 1 Year |
| Highlight: | 1x10 4K Video Wall Controller,1.8mm Bezel LCD Video Wall Controller,1x10 TV Video Wall Controller |
||
1.8mm Bezel 1 In 10 Out 1x10 2x5 4K Video Wall Controller For LCD Screen
4K 1 IN 10 OUT video wall processor
1. Overview
The COM port control is pre installed, and the splicing mode can be controlled by sending switching
instructions through the serial port device.With audio decoding function and audio output interface,
video signal and audio signal can be output synchronously.
2.Dimension(Unit: mm)
6- Channel/8- Channel/10- Channel/12- Channel model size
3.Specification
| HDMI Input | ||
| Interface | HDMI(HDMI 1.4) | |
| Resolution | Up to 3840X2160@30Hz | |
| Color | 24bit,16.77M | |
| Output | ||
| HDMI Interface | HDMI(HDMI 1.4) | |
| Splicing output resolution | Up to 3840x2160 / 30Hz (4K interpolation effect) | |
| Color | 24bit,16.77M | |
| Audio output | 3.5mm stereo socket | |
| Other | ||
| control mode | Mode selection button, COM port command control splicing mode, remote control splicing control (optional) | |
| Power Supply | DC12V 2A power adapter | |
| Specifications | ||
| 4-Channel model | Size | 310mm x 104mm x 28mm |
| Weight | 1.37kg (Including accessories) | |
| 6-Channel model | Size | 360mm x 102.7mm x 47mm |
| Weight | 1.95kg(Including accessories) | |
| 8-Channel model | Size | 360mm x 102.7mm x 47mm |
| Weight | 1.96kg(Including accessories) | |
| 10-Channel model | Size | 360mm x 102.7mm x 47mm |
| Weight | 2.10kg(Including accessories) | |
| 12-Channel model | Size | 360mm x 102.7mm x 47mm |
| Weight | 2.11kg(Including accessories) | |
4. System Topology
