Product Details:
|
| Display Resolution: | 1920x1080 | Contrast Ratio: | 3000:1 |
|---|---|---|---|
| Output Signal: | HDMI/VGA/AV/YPbPr/USB | Input Signal: | HDMI/VGA/AV/YPbPr/USB |
| Control Method: | Remote Control/RS232 | Name: | LCD Video Wall Controller |
| Video Resolutions: | Up To 3840×2160 @ 60Hz (4K UHD) | Video Inputs: | HDMI, VGA, DVI, DisplayPort |
| Highlight: | 2x2 LCD Video Wall Controller,HDMI Output LCD Video Wall Controller |
||
The LCD Video Wall Controller is a core device designed to manage multiple LCD screens, transforming them into a large, seamless video wall. This controller is widely used in surveillance centers, command rooms, corporate meeting spaces, and advertising displays, making it an essential solution for industries that require high-quality visuals on large displays. The LCD Video Wall Controller distributes input video signals to multiple LCD displays, supporting various display modes such as full screen, split screen, zoom, and overlay. With its high-performance image processing capabilities, the controller ensures crisp, smooth visuals, even at high resolutions.
| Name | Specification |
| Input signal | |
| VGA |
HD15 interface and link with 1 audio interface of 3.5 Support 640*480/85HZ to 1920*1200/60HZ |
| HDMI | HDMI 1.4(HDCP 1.3) DVI 1.0 ,HDMI embed audio |
| Video | Automatic identification the syetem of NTSC,PAL and SECAM,link with 1 audio interface of 3.5 |
| USB |
Standard interface of 2.0,can insert U disk,embed audio; Support video,image,MP3,TXT |
| Output signal | |
| HDMI interface |
25 HDMI output,support joint pattern of 2*2,1*4,4*1; Support customizing output signal of 2 to 25; 1920*1080P/60HZ,1280*720,60HZ; |
| Audio | 3.5 Audio interface,support left and right channels and stereo,AV signal switch synchronously |
| others | |
| Control mode | RS232,Remote ,case key |
| Power supply | AC: 100 to 240 V |
| Joint pattern | Quad standard joint,single machine customize joint of 2 to 25 |
| Power | 20W |
| Case size | |
| Dimensions(1U) | 1U 19 inch standard crate,442mm(L)*45mm(H)*242mm(W) |
| Weight(1U) | 2.5KG |
The LCD Video Wall Controller is a versatile, high-performance, and cost-effective solution for creating impressive video walls. Its advanced features, wide range of applications, and reliable performance make it a must-have for any organization or event looking to make a statement with their displays.
