Product Details:
|
| Max. Power Consumption: | 20W | Output Resolution: | Up To 4Kx2k@60Hz |
|---|---|---|---|
| Video Bandwidth: | 225MHz | Input Resolution: | Up To 1080p |
| Compliance With: | HDMI1.3a, HDCP1.2 | Compatibility: | HDMI 2.0, HDCP 2.2, HDR, 3D |
| Inputs: | HDMI, VGA, DVI, Component, Composite | Outputs: | HDMI, VGA, DVI, Component, Composite |
| Highlight: | 4Kx2k 60Hz HDMI Matrix Switcher,DVI Outputs HDMI Matrix Switcher,HDCP2.2 HDMI Matrix Switcher |
||
The HDMI Matrix Switcher represents a pinnacle in video and audio signal distribution, offering unparalleled flexibility and control for a multitude of multimedia needs. With a robust array of input and output options including HDMI, VGA, DVI, Component, and Composite, this device is designed to cater to a wide range of professional settings, from corporate conference rooms to home theater systems.
High bandwidth capability is another standout feature of this Video Matrix Switcher, with an impressive 18Gbps 4 x 4 HDMI Matrix ensuring that high-resolution video including 4K and 3D content can be transmitted flawlessly. This bandwidth allows for the transmission of rich media with high dynamic range (HDR) content, guaranteeing that the video quality is maintained at its highest possible level.
| Specification | Description | |
| Input Port Count | Available options include 4, 8, 16, etc. | |
| Output Port Count | Available options include 4, 8, 16, etc. | |
| Video Interface | HDMI Type A Female Connector | |
| Input Level | TMDS 2.9V/3.3V | |
| Output Level | TMDS 2.9V/3.3V | |
| Input Impedance | 50Ω | |
| Bandwidth | 6.75Gbit/s (fully digital) | |
| Switching Speed | Maximum 200ns | |
| Signal Resolution | Supports 1920x1200@60Hz, 2048x1080@24Hz, and other formats | |
| Signal Format | HDMI 2.0 Standard, TMDS Signal | |
| Signal Management | Supports EDID and DDC Management | |
| Audio Processing | Supports audio signal transmission and processing | |
| Control Method | Manual control via front panel, remote control, software control via computer, etc | |
| Stability | Features overcurrent protection, overvoltage protection, | |
|
undervoltage protection, and other functions |
||
The Winlink HDMI Matrix Switcher, model WLP-HD0404K, is an advanced audio and video signal management solution designed to cater to various application scenarios.
The applications of HDMI matrix switchers are quite extensive. Primarily, they are used in the following scenarios:
1.Home Entertainment Systems: In home entertainment systems, HDMI matrix switchers enable the switching of multiple HDMI sources (such as TVs, DVDs, game consoles, cameras, etc.) to a single television or projector. This allows users to easily switch between different entertainment devices and enjoy the visual and audio experience brought by high-definition content.
2.Business Presentations and Educational Training: HDMI matrix switchers play a crucial role in business presentations and educational training sessions. They facilitate the switching of multiple HDMI sources (like computers, projectors, cameras, etc.) to one or multiple display devices, enabling more flexible presentation options.
3.Conference Rooms and Control Centers: In conference rooms and control centers, HDMI matrix switchers enable the seamless switching of various HDMI sources (such as computers, video conferencing equipment, surveillance cameras, etc.) to one or multiple display devices. This enhances the efficiency of meetings and control operations.
Moreover, HDMI matrix switchers boast advantages like high-definition picture quality, high-speed transmission, multi-path switching, strong compatibility, and ease of operation. These features make them suitable for various scenarios, enhancing overall usage efficiency and flexibility.
