Product Details:
|
| Display Resolution: | 1920x1080 | Power Supply: | AC100-240V |
|---|---|---|---|
| Control Method: | Remote Control/RS232 | Input Signal: | HDMI/VGA/AV/YPbPr/USB |
| Hdmi Output: | 1024*768@60hz,720P@60Hz,1080P@60Hz | Wall Modes: | 2x2 ,2x3,3x2,4x1,4x2,3x3,etc, |
| Input Ports: | HDMI, DVI, VGA, DisplayPort | Output Ports: | DisplayPort, DVI Loop Out |
| Highlight: | 2x2 LCD Video Wall Controller,2x3 LCD Video Wall Controller,3x2 LCD Video Wall Controller |
||
The LCD Video Wall Controller is a cutting-edge product designed to enhance the visual display of multiple screens. It serves as a central hub for controlling and managing the content displayed on a video wall, making it an essential tool for businesses, schools, and other organizations.
The LCD Video Wall Controller operates on a wide range of power supply, from AC100 to AC240 volts. This makes it suitable for use in different countries and regions, providing users with a convenient and versatile solution.
The controller supports a 16:9 display ratio, the most commonly used aspect ratio in the industry. This ensures that the content displayed on the video wall is optimized for a wide range of applications, from video presentations to digital signage.
With a display resolution of 1920x1080, the LCD Video Wall Controller delivers stunning and crisp visuals on the video wall. This high-resolution display ensures that every detail of the content is accurately portrayed, providing an immersive viewing experience for the audience.
The LCD Video Wall Controller offers two convenient control methods: remote control and RS232. With the remote control, users can easily manage and adjust the settings of the video wall from a distance. The RS232 control allows for a more advanced and precise control of the video wall, making it ideal for professional use.
In conclusion, the LCD Video Wall Controller is an essential and versatile tool for managing and optimizing the display of video walls. With its advanced features, wide compatibility, and convenient control methods, it is the perfect solution for businesses and organizations looking to enhance their visual displays.
| Item | Specification |
| HDMI input | |
| Interface | HDMI(support HDCP1.3 and DVI1.0) |
| Resolution | Up to 1920*1080@60Hz |
| Color | 24bit,16.77M |
| DVI input | |
| Interface | DVI(support DVI1.0) |
| Resolution | Up to 1920*1080@60Hz |
| Color | 24bit,16.77M |
| VGA input | |
| Interface | DB15 |
| Resolution | 800*600 to 1920*1080@60Hz |
| AV input | |
| Interface | RCA |
| Identification | Auto |
| Standard | PAL,NTSC |
| USB | |
| Video | RM,RMVB,AVI,WMV,MOV,MP4,FLV,MPG,DAT,MPEG and so on, the resolution up to 1080P |
| Audio | MP3,WMA,FLAC and so on |
| Picture | JPG,BMP,PNG |
| Text | TXT |
| Audio in | Fit for VGA video |
| Audio output | Fit for output video |
| HDMI output | 1024*768@60hz,720P@60Hz,1080P@60Hz |
| Controller | Remote, button key, RS232 serial port |
| Power | Input:DC 12V3A |
| Dimension (package) |
4 Port: 340mm(L)x200mm(W)x60mm(H) 5~10 Port: 420mm(L)x243mm(W)x60mm(H) |
| Weight |
4 port: 1.6 Kg 5~10 port: 2.5 KG |
The LCD Video Wall Controller is perfect for a variety of applications and scenarios. Some of the most common uses include:
