Product Description:
The 1x6 video wall controller is a professional-grade HDMI splitter designed to transform one video source into a stunning six-screen synchronized display. With 1 HDMI input and 6 HDMI outputs, this controller enables seamless video distribution for 2x3 or 1x6 video wall configurations — ideal for businesses, digital signage, surveillance systems, or multimedia rooms.
Engineered with robust hardware and zero-lag processing, this lcd wall controller supports Full HD 1080p resolution and maintains perfect synchronization across all connected displays. It’s fully compatible with most LCD/LED TVs and monitors, making it a versatile choice for any 6 TV video wall controller application.
Setup is fast and simple — just plug in your source and displays, and the system is ready to go. No software or configuration required.
Key Features:
1 HDMI In / 6 HDMI Out — Supports horizontal (1x6) and matrix (2x3) screen layouts
Full HD 1080p Output — Delivers sharp, detailed video on every display
Built-in Signal Processing — Smart scaling and real-time output adjustment
road Compatibility — Works with all mainstream brands of LCD and LED screens
Audio Pass-through Support — HDMI audio transmission without loss
Plug & Play Installation — No drivers, no network setup, no hassle
HDCP 1.2 Compliant — Ensures content protection compatibility
Technical Parameters:
| Specification Item |
Details |
| HDMI Input |
1 Port (HDMI 1.3) |
| HDMI Output |
6 Ports |
| Supported Input Format |
480i to 1080p @60Hz |
| Max Output Resolution |
1920x1080 @60Hz |
| HDCP Version |
1.2 |
| Supported Audio Formats |
PCM 2.0 |
| Power Supply |
DC 12V 2A |
| Working Temperature |
0–60°C |
| Device Size |
240mm x 110mm x 25mm |
| Net Weight |
850g |
| Control Method |
Manual button control |
Applications Scenarios:
This 1x6 video wall controller is widely applicable across various multi-screen display environments, especially where synchronized HD output and seamless video wall set ups are essential. Whether for information display or immersive visual interaction, it offers a stable and high-performance solution.
Ideal for the following use cases:
Retail & Digital Signage — Create eye-catching wall displays in shopping centers
Industrial Control & Monitoring — Perfect for data centers and operation rooms
Educational & Training Environments — Visual learning with wide display formats
Events & Public Venues — Powerful multi-screen performance for live content
Home Entertainment Walls — Build your own mini theater or gaming wall
Exhibits & Media Installations — Synchronized content delivery across screens
