Product Details:
|
| Network Protocol Support: | Dante Audio Networking Protocol | Audio Quality: | 24-bit/192 KHz |
|---|---|---|---|
| Delay: | Less Than 1 Millisecond | Power Supply: | DC 12V/3A |
| Video Wall Mode: | Full Screen, PIP, PBP, Customized | Weight: | 2.5KG |
| Working Temperature: | -20℃~60℃ | ||
| Highlight: | rs232 dante audio controller,dante audio controller 1920x1080,rs232 dsp processor |
||
Description:
Dante Audio Controller is designed to simplify the management of audio distribution in complex systems by providing intuitive control over the network's audio routing and configuration. It supports seamless integration with various Dante-enabled devices, offering flexibility and scalability in audio system setups. The controller allows real-time monitoring and ensures reliable, low-latency audio transmission across multiple endpoints.
Key Specifications
Network Protocol Support:
Fully supports Dante audio networking protocol.
Compatibility with AES67 and SMPTE 2110 standards for broader interoperability.
Channel Capacity:
Capable of managing hundreds of audio channels simultaneously.
Allows for both unicast and multicast audio routing.
Latency and Synchronization:
Ultra-low latency performance, typically below 1ms.
Automatic sample rate conversion and precise clock synchronization.
Control Interface:
User-friendly software interface for easy setup and configuration.
Available for both Windows and macOS platforms.
Supports drag-and-drop routing of audio channels and real-time adjustments.
Scalability:
Scalable architecture to accommodate both small-scale installations and large-scale audio networks.
Allows for easy addition of Dante-enabled devices to expand the system.
Specifications:
Item | Specifications |
| Max Input Level | 18dBu |
| Max Output Level | 18dBu |
| Default Output Level | 0dBu |
| THD+N | <0.003%；1kHz@+4dBu <0.0035%；1kHz@+10dBm <0.0035%；20Hz～20kHz@+4dBu |
| Frequency Response | 20Hz-20kHz, +/-0.2dB |
| In To Out dynamic range | 110dB (Unrecorded right) |
| S/N | -110dB (Unrecorded right) |
| ADC Dynamic Range | CS5361 114dB |
| DAC Dynamic Range | CS4382A 114dB |
| DSP | 400Mhzfloating - point SHARC ADSP-21488 |
| Sampling Frequency | 48K |
| QE | 24Bit |
| Storage | 32 |
| Control Mode | 100M Ethernet |
| Language | English |
| Noise Gate | Yes |
| Feedback | Yes |
| Signal Generator | Yes |
| Pressure Limiter | Independent 12 channel |
| Delay | Output 1-4 218ms Output 5-8 148ms |
Dante Application:
Dante Audio Controller is widely used in various professional audio environments. Here are some key application areas:
Live Sound and Events:
Dante Audio Controller used in concerts, theaters, and live events for managing multi-channel audio distribution to different sound systems and monitoring stations.
Provides flexibility in audio routing to adapt to different stage and venue setups.
Broadcast and Recording Studios:
Dante Audio Controller ideal for audio production, recording, and broadcasting facilities to streamline the distribution of high-quality audio to different control rooms and equipment.
Allows precise control over audio routing in complex studio environments.
Corporate AV and Conferencing:
Utilized in corporate offices, conference rooms, and meeting spaces for distributing audio across multiple zones.
Supports seamless integration with AV systems for high-quality audio during video conferences and presentations.
Educational Institutions:
Deployed in schools, universities, and training centers for distributing audio to lecture halls, auditoriums, and other teaching areas.
Enables easy control over multi-room audio setups and public announcement systems.
Houses of Worship:
Dante Audio Controller used in churches, mosques, and other religious institutions to manage audio distribution for sermons, live music, and spoken word.
Provides clear audio signal routing to various areas within the worship facility.
Hospitality and Retail:
Applied in hotels, restaurants, and retail environments to create immersive soundscapes.
Allows centralized control of background music, announcements, and event audio across multiple zones.
