Product Details:
|
| Processor: | ADI SHARC 21489 | Sampling Rate/Digitalizing Bit: | 48K/24bit |
|---|---|---|---|
| Input Gain: | 0/6/12/18/24/30/36/42/48 DBu | Phantom Power: | 48V/10mA Max |
| Frequency Response (20~20KHz): | ±0.5dB | Product Name: | Tv Speaker Remote Usb Audio Controller With Auto Rca Volume Control |
| Highlight: | HDMI Bidirection Switcher,RoHs HDMI Bidirection Switcher,HDMI Splitter Bidirectional |
||
Description:
Dante Controller provides essential device status information and powerful real-time network monitoring, including
device-level latency and clock stability stats, multicast bandwidth usage, and customized event logging, enabling you
to quickly identify and resolve any potential network issues. You can also quickly and easily backup, restore, move, and
reuse Dante network configurations using Presets, and edit Dante routing configurations offline.
Tv Speaker Remote Usb Audio Controller With Auto Rca Volume Control.
Specifications:
|
Item
|
Specifications |
| Max Input Level | 18dBu |
| Max Output Level | 18dBu |
| Default Output Level | 0dBu |
| THD+N | <0.003%；1kHz@+4dBu <0.0035%；1kHz@+10dBm <0.0035%；20Hz～20kHz@+4dBu |
| Frequency Response | 20Hz-20kHz, +/-0.2dB |
| In To Out dynamic range | 110dB (Unrecorded right) |
| S/N | -110dB (Unrecorded right) |
| ADC Dynamic Range | CS5361 114dB |
| DAC Dynamic Range | CS4382A 114dB |
| DSP | 400Mhzfloating - point SHARC ADSP-21488 |
| Sampling Frequency | 48K |
| QE | 24Bit |
| Storage | 32 |
| Control Mode | 100M Ethernet |
| Language | English |
| Noise Gate | Yes |
| Feedback | Yes |
| Signal Generator | Yes |
| Pressure Limiter | Independent 12 channel |
| Delay | Output 1-4 218ms Output 5-8 148ms |
| PEQ Low Shelf High Shelf |
Independent 16-band |
| High Pass/Low Pass Bessel Butterworth Link-Riley |
Independent 12 channel -6dB/oct -12dB/oct -18dB/oct -24dB/oct -36dB/oct -48dB/oct |
| Product name |
Tv Speaker Remote Usb Audio Controller With Auto Rca Volume Control |
Typical System Application:
Dante Application: Dante network breaks through space limitations, and has a wide range of application scenarios.
It can connect all devices that support Dante protocol to the same local area network. By cascading 2 DSPs,
it supports the access of up to 32 analog microphones and 32 Dante microphones. Each processor will
conduct first-level auto mixing on its own microphones, and the second-level auto mixing is then made
on the mixed signal via the auto mixer of main processor so that more microphones can be connected
to build a larger auto mixing matrix. The two-level auto mixing working mode can satisfy general application scenarios.
Tv Speaker Remote Usb Audio Controller With Auto Rca Volume Control.
