2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode

2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode
2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode
2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode 2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode 2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode

Large Image :  2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode

Product Details:
Place of Origin: Mainland China
Brand Name: VINCAN
Certification: CE,FCC and RoHs
Model Number: WLRS-TW14
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Carton box and standard export package
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 pcs per week
Contact Now

2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode

Description
Product Name: 2X2 Lcd Video Screen Wall Controller Hdmi Audio: 3.5 Audio Interface,support Left And Right Channels And Stereo,AV Signal Switch Synchronously
Power: 20W Dimensions(1U): 1U 19 Inch Standard Crate,442mm(L)*45mm(H)*242mm(W)
Color: Black Casing Material: Metal
Highlight:

2X2 LCD Screen Controller

,

1U LCD Screen Controller

,

2X2 Multiple Monitor Controller

2X2 LCD Screen Controller HDMI Video Wall Multiple Splice Mode



2X2 lcd video screen wall controller hdmi



1, Product introduction:

Product can be control by infrared remote control,case button control or RS-232 , which user can master it more easily and intuitively while operate it. It as well more humanization and simple for user can one-click quick control and global function control by IR or case button.



2, Function Introduction:

name Specification
Input signal
VGA

HD15 interface and binding1 audio interface of 3.5

Support 640*480/85HZ to 1920*1200/60HZ
HDMI HDMI 1.4(HDCP 1.3) DVI 1.0 ,HDMI embed audio
Video Automatic identification the system of NTSC,PAL and SECAM,binding 1 audio interface of 3.5
USB

Standard interface of 2.0,can insert U disk,embed audio;

Support video,image,MP3,TXT
Output signal
HDMI interface

4 HDMI output,support joint pattern of 2*2,1*4,4*1;

Support customizing output signal of 2 to 25;

1920*1080P/60HZ,1280*720,60HZ;
Audio 3.5 Audio interface,support left and right channels stereo,audio signal switch synchronously
others
Control mode Remote,RS-232
Power supply DC:12V
Joint pattern Quad simple joint
Power 20W
Chassis Specifications
Dimensions 269mm(L)*43mm(H)*157mm(W)
Weight 1.1kg



3, System Topology



 2X2 LCD Screen Controller HDMI Video Wall Multiple Splice mode 0
