Product Details:
|
| Number Of Dante Channels: | 20 | DANTE Network Interface: | 20 |
|---|---|---|---|
| Phantom Power (per Input): | 48V | DSP Processing: | Ti 456MHz FLOPS DSP |
| Frequency Response（20~20KHz）: | ±0.2dB | Product Name: | Sound Processor Digital Sound Processor Audinate Controller |
| Highlight: | 18W HDMI Splitter Switcher,18W Smart HDMI Switch,8bits HDMI Splitter Switcher |
||
Description:
1.Industry advanced Dual-core ADI SHARC DSP processor, 500MHz (3.0 GFLOPS) per core, 64-bit floating point;
2.Fully open architecture, flexible software design;
3.Up to 8 I/O card slots;
4.Analog in/out, AEC and USB card;
5.Optional Dante channels from 8x8 to 64x64;
6.Multi-channel audio player and recording;
7.Support Hot-plug;
8.Support cascading for large applications;
9.4x 1000M RJ45 for Dante audio transmission;
10.8x GPIOs, RS232 and RS485 control;
11.Redundant power supply;
12.Firmware update OTA;
13.Standard and 1 U 2U size;
14.Sound Processor Digital Sound Processor Audinate Controller.
Specification :
|
Item
|
Specifications |
| Max Input Level | 18dBu |
| Max Output Level | 18dBu |
| Default Output Level | 0dBu |
| THD+N | <0.003%；1kHz@+4dBu <0.0035%；1kHz@+10dBm <0.0035%；20Hz～20kHz@+4dBu |
| Frequency Response | 20Hz-20kHz, +/-0.2dB |
| In To Out dynamic range | 110dB (Unrecorded right) |
| S/N | -110dB (Unrecorded right) |
| ADC Dynamic Range | CS5361 114dB |
| DAC Dynamic Range | CS4382A 114dB |
| DSP | 400Mhzfloating - point SHARC ADSP-21488 |
| Sampling Frequency | 48K |
| QE | 24Bit |
| Storage | 32 |
| Control Mode | 100M Ethernet |
| Language | English |
| Noise Gate | Yes |
| Feedback | Yes |
| Signal Generator | Yes |
| Pressure Limiter | Independent 12 channel |
| Delay | Output 1-4 218ms Output 5-8 148ms |
| PEQ Low Shelf High Shelf |
Independent 16-band |
| High Pass/Low Pass Bessel Butterworth Link-Riley |
Independent 12 channel -6dB/oct -12dB/oct -18dB/oct -24dB/oct -36dB/oct -48dB/oct |
| Product name | Sound Processor Digital Sound Processor Audinate Controller |
3.Typical System Application:
Dante Application: Dante network breaks through space limitations, and has a wide range of application scenarios.
It can connect all devices that support Dante protocol to the same local area network. By cascading 2 DSPs,
it supports the access of up to 32 analog microphones and 32 Dante microphones. Each processor will
conduct first-level auto mixing on its own microphones, and the second-level auto mixing is then made
on the mixed signal via the auto mixer of main processor so that more microphones can be connected
to build a larger auto mixing matrix. The two-level auto mixing working mode can satisfy general application scenarios.
Sound Processor Digital Sound Processor Audinate Controller.
