Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control

Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control
Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control

Large Image :  Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control

Product Details:
Place of Origin: Mainland China
Brand Name: VINCAN
Certification: CE,FCC and RoHs
Model Number: WL88
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Carton box and standard export package for Optical Kvm Switch 4x2 Kvm Fiber Matrix Switch Fiber Kvm Switch
Delivery Time: 2-3 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1000 sets per week
Contact Now

Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control

Description
Product Name: Fiber KVM Matrix Node With Integrated SFP I/O Cards, 4K 4:4:4 Support, And Video Wall Control Communication Port: Fiber SFP X4
Resolution: 3840x2160 4:4:4 And Downward Compatibility Image Processing: Advanced FPGA
Protocol: HDCP, HDMI2.0, HDMI 1.4 Compatible With DVI 1.0 Bandwidth: Up To 12 GB Per Channel
Highlight:

4x2 fiber KVM switch

,

optical KVM matrix switch

,

fiber KVM switch with warranty

Description:


Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control is
designed with two standalone channels to transmit

UHD Video + Audio + USB-HID + RS232/485 + IR over fiber optic up to 20 km, with original image
quality and nearly zero latency. It would be configured as transmitter of a all-in-one Visualized & Distributed
Fiber KVM and Video Wall Control System or a KVM Extender or a KVM Matrix.

  • Applications: Control Room, Network Operation Center (NOC), Security Operation Center (SOC),

  • Emergency Operation Center (EOC), Joint Operation center(JOC), Airport Operation Center(AOC),

  • Traffic Operation Center(TOC), Board Room, Meeting Room, etc.

  • Industries: Government, Public Security, Finance, Telecomm, Energy & Utility, Oil & Gas, Transportation,

  • Aviation, Military & Defense, Armed Force, Smart City, Broadcasting, Sea Port, Offshore, Enterprise, etc.





Specification for Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control​:


Video Port HDMI INx2, HDMI LOOP OUT x2
Audio Port 3.5 mm Analog INx2
Control Port RS232 x2, RS485 x2, IR/IO x4, USB2.0 x2
Communication Port Fiber SFP x4
Resolution 3840x2160 4:4:4 and downward compatibility
Image Processing Advanced FPGA
Protocol HDCP, HDMI2.0, HDMI 1.4 compatible with DVI 1.0
Bandwidth up to 12 GB per channel
Transmission Distance up to 20 km over fiber optic
Audio Control audio matrix switching, audio mixing, embed and de-embed feature.
Power Supply 12V 2.6A Adapter, available to make power redundancy



Fiber KVM Matrix Node with Integrated SFP I/O Cards, 4K 4:4:4 Support, and Video Wall Control 0
