Product Details:
|
| Product Name: | Usb-c Dual Hdmi 4k&1080p Wireless Hdmi Display Dongle Adapter | Output Resolutions Support: | HDMI: Up To 1080P VGA: Up To WUXGA(1920x1200) |
|---|---|---|---|
| Frame Rate: | Up To 30 Fps | Wireless Transmission Technology: | WIFI |
| Band: | 2.4GHz, 5GHz | Data Rate Wireless: | Up To 867Mbps |
| Highlight: | 867Mbps HDMI Display Dongle Adapter,1080P HDMI Display Dongle Adapter,Wireless HDMI Display Dongle Adapter |
||
USB-c dual hdmi 4k&1080p wireless hdmi display dongle adapter
Specification :
| Technical | |
| Input | USB, Type A male |
| Output |
1 x HDMI, Type A 19-pin female 1 x VGA, D-SUB female 1 x Stereo out, 3.5mm ear jack |
| Recommended operating system | Windows 7/8.1/10, 32/64 bit, Mac OS X 10.10/10.11/10.12, Android 5.0/6.0, iOS 9/10 |
| Input resolutions support | Up to 3840x2160 |
| Output resolutions support |
HDMI: Up to 1080P VGA: Up to WUXGA(1920x1200) |
| Frame rate | Up to 30 fps |
| Audio | PCM stereo |
| Audio Bit | 16bit |
| Audio Sample Rate | 44.1KHz |
| Wireless transmission technology | Wi-Fi |
| Band | 2.4GHz, 5GHz |
| Reach | Max. 30m (100 ft.) between Button and Base Unit |
| Wireless transmission protocol | IEEE 802.11n/ac |
| Data rate wireless | Up to 867Mbps |
| Authentication protocol | WPA2-PSK |
| Encryption | AES CCMP |
| Number of simultaneous on screen | 1 |
| Number of simultaneous connections | 16 |
| iOS/Android portable devices compatibility | iOS/Android mirroring |
| System requirements |
PC minimum requirements: CPU: Intel Pentium Dual Core, 1.83GHz Memory: 2048 MB RAM PC recommended requirement: CPU: Intel Pentium Dual Core, 2.6GHz Memory: 4096 MB RAM MAC: CPU: Intel Core 2 Duo Memory: 2048 MB RAM |
| General | |
| Operating Temperature | 41~104°F (5~40°C), 10% to 90%, noncondensing |
| Storage Temperature | 14~140°F (-10~60°C), 10% to 90%, noncondensing |
| Humidity | 10% to 90%, noncondensing |
| ESD Protection |
Human body model: +/- 8KV (air-gap discharge) +/- 4KV (contact discharge) |
| Power Supply | 12V DC |
| Power Consumption (Max.) |
Base Unit: 6 Watts Button: 2 Watts |
|
Device Dimension |
Base Unit: 7.4”x1.6”x4.3” (188mmx40mmx110mm) Button: 3.2”x0.6”x2.0” (80mmx15mmx50mm) |
|
Package Dimension (W x H x D) |
11.7”x2.4”x8.7” (298mmx61mmx221mm) |
| Weight | 4.19 lbs. (1.9kg) |
| Product name | 4k wireless hdmi display dongle adapter 1080p wifi streaming |
