Product Details:
|
| Compatibility: | HDMI 2.0 | Video Interface: | HDMI |
|---|---|---|---|
| Power Supply: | DC 12V 2A | HDMI Resolution: | 1080P/1080i/720P/576P |
| HDCP Version: | HDCP2.2 | Power Adapter Format: | ..Input AC (50Hz.60Hz) 100- 240V |
| RS232: | Support | Transmission Distance: | 4Kx2K@60Hz 70m，1920x1080@60Hz 100m |
| Highlight: | 70m HDMI HDBaseT Extender,2.0 HDMI HDBaseT Extender,HDMI 2.0 HDMI HDBaseT Extender |
||
This 18Gbps HDMI HDBaseT Extender transmits high-definition video, RS-232, bidirectional IR control, and internet signals up to 328 feet (100 meters) over a single CAT6/6a cable. Supporting resolutions up to 4K2K@60Hz 4:4:4, it ensures exceptional image quality. The transmitter features ARC (Audio Return Channel) functionality and local audio extraction, while the bidirectional IR passthrough allows remote control of both source and display devices. Additionally, the extender supports PoC (Power over Cable), simplifying installation by eliminating the need for separate power supplies. This HDMI extender is ideal for applications requiring high-quality HDMI signal transmission over long distances, such as multimedia conferences, home theaters, and educational training environments.
☆ HDCP 2.2 / 1.x and DVI 1.0 compliant
☆ Support 18Gbps video bandwidth
☆ Video resolution is up to 4k2k@60Hz YUV 4:4:4 High bit rate audio transmission via HDMI
☆ The maximum transmission distance is 328ft / 100 meters via a single CAT6/6a cable
☆ Support PoC (Power over Cable) function
☆ Support ARC (Audio Return Channel) function
☆ Support bi-directional IR, RS-232 and LAN signal pass-through transmission
☆ HDR, HDR10+, Dolby Vision and HLG function supported
☆ Compact design for easy and flexible installation.
| Power adapter format | Input AC (50Hz-60Hz) 100-240V |
| HDCP version | HDCP 2.2 |
| HDMI resolution | 1080P/1080i/720P/576P |
| Power Supply | DC 12V 2A |
| Compatibility | HDMI 2.0 |
| Video Interface | HDMI |
| Video Resolution | 4K@60Hz |
| Transmission distance | 4Kx2K@60Hz 70m,1920x1080@60Hz 100m |
| Product Name | 4K 100m HDMI HDBaseT Extender |
The Winlink HDMI HDBaseT Extender is a high-performance solution for transmitting high-definition video and audio signals over long distances. Utilizing advanced HDBaseT technology, it delivers uncompressed 4K video and audio over a single CAT5e/6/6a cable up to 100 meters (328 feet), ensuring superior image and sound quality.
Home Theater: Transmit 4K HDR from gaming consoles/Blu-ray players via 4K HDBaseT Extender (HDMI Extender Kit) with zero latency.
Conference Rooms: Extend 4K laptop/PTZ camera feeds over HDMI Extender over HDBaseT, enabling KVM control up to 100m.
Digital Signage: Deploy 4K ads across 150m via HDBaseT Extender Kit, HDCP 2.2 compliant.
Education: Stream 4K lectures to interactive displays using HDMI over HDBaseT wall plate extender.
Pro AV: Power large-scale 4K systems with 18Gbps HDBaseT Extender Kit (PoC supported).
