Product Description:
The HDMI HDBaseT Extender using the next-generation connectivity technology HDBaseT™, this HDMI HD HBaseT Extender uses no delay, no compression transmission technology, support 1080P@60 Hz extend 70m or 100m over Cat6, and 4K@30Hz extend 35m or 70m over Cat6, otherwise pass-thru RS232 and IR. This hdmi extender can be connected to other standard HDBaseT device. Widely used in home theater, exhibition display and command center, etc.the best hdmi extender over cat6.
Features:
- Long-Distance HDMI Transmission: HDMI HDBaseT Extender supports up to 70m (1080P) or 40m (4K UHD) over a CAT6 cable.
- High-Resolution Support: HDBaseT extender compatible with 4K@30Hz, 1080P@60Hz, 3D, Deep Color.
- Zero Latency, Uncompressed Transmission: Utilizes HDBaseT technology for lossless video transmission, ideal for high-quality video applications.
- Support 7.1 channel and LPCM, Dolby TrueHD, DTS-HD Master Audio.
- Support EDID&HDCP pass-thru.
- Support RS232 pass-thru, baud rate: 110~115200bps.
- hdmi extender easy installation
Technical Parameters:
| Category |
Parameter |
Specification |
| Video |
Version
|
HDMI2.0 HDCP2.2 |
| |
Support Resolution |
4096×2160@60Hz 4:2:0, 3840×2160@60Hz 4:2:0, 3840×2400@30Hz,
3840×2160@30Hz, 1920×1200@60Hz, 1920×1080@60Hz
|
| |
Connector |
Type A HDMI female |
| IR |
Specification |
Support 0~38KHz |
| |
Distance |
1920×1200@60Hz extend 100m/70m by Cat6,
4K×2K@60Hz extend 70m/35m by Cat6
|
| Other |
Power Consumption |
>5W |
Applications:
HDBaseT Extender is widely used for long-distance HDMI transmission over a single Cat5e/6/7 cable, ensuring uncompressed video, audio, control signals, and power transmission. Below are the HDMI Extender's key applications:
HDMI cat5 extender good for Home Theater & Multimedia Entertainment
Conference Rooms & Business Presentations with HDBaseT Extender
Digital Signage & Retail Advertising
Security & Surveillance Systems
Education & Training Rooms&hdmi to hdmi extender
