Product Details:
|
| Audio Format: | PCM, Dolby Digital, DTS | Control Bs Control: | No Need To Install Any Client Software |
|---|---|---|---|
| Dimension: | 258mm(L)134xmm(W)x34mm(H) | Ethernet Control Port: | RJ-45 Female Ports, TCP/IP Protocol |
| Image Adjustment: | Brightness, Contrast, Saturation, Hue | Outputs: | 9 Channels HDMI Output Port |
| Resolution: | Max. 1920x1080P@60Hz | Resolution Support: | Up To 1080p |
| Size: | 195mm(L)*139mm(D)*38mm(H) | ||
| Highlight: | 9 Channels HDMI Video Wall Controller,Seamless Display HDMI Video Wall Controller |
||
The HDMI Video Wall Controller is a specialized device designed for multi-screen display and video wall splicing. It allows a single HDMI signal source to be distributed across multiple screens, delivering high-resolution video output and dynamic display effects. This video wall controller supports flexible screen layout configurations and features an intuitive user interface for easy operation and management. Whether used for surveillance, digital signage, or presentation systems, this controller ensures exceptional image quality and smooth video performance.
Technical Parameters:
| Product Name | HDMI Video Wall Controller |
|---|---|
| Display Mode | Full Screen, Zoom, Auto |
| Video Format | RGB, YUV444, YUV422, YUV420 |
| Video Resolution | Up to 4K Ultra HD (3840x2160) @ 60Hz |
| Splicing Modes | 2x2, 3x3, 4x4, and customizable layouts |
| Control Methods | RS-232, infrared remote control, Ethernet (LAN) control |
| Audio Format | PCM, Dolby Digital, DTS |
| Output ports | 4 x HDMI (options available for 8x, 16x outputs) |
| Input ports | 1 x HDMI, 1 x DVI, 1 x VGA |
| Power Supply | AC 100-240V, 50/60Hz |
