Product Details:
|
| Input Signal(optional): | HDMI/DVI/VGA/AV/YPbPr/fiber | Output Signal Format: | DVI/VGA/AV/YPbPr/HDMI |
|---|---|---|---|
| Output Resolution: | Up To 1920*1200/60HZ | System Control Software : | Control Software |
| Resolution: | Up To 3840X2160@30Hz | Product Name: | Custom Made 4k 2x2 2x4 HDMI Video Wall Controller Systems For LCD Video Display Screens |
| Highlight: | FCC Video Wall Controller System,2x4 Video Wall Controller System,100VAC HDMI Video Wall Controller |
||
Custom Made 4k 2x2 2x4 HDMI Video Wall Controller Systems For LCD Video Display Screens
Description:
Our video wall processor products enable the display of multiple sources across projector screens, video walls,
or a display wall. With big data getting bigger every day, visualizing a variety of content and sharing information
for collaborative analysis means it's crucial to choose the display system that best meets your needs.
Technical Parameters:
| HD digital video wall processor | |
| Description | Up to sixteen video windows per display channel (Optional) |
| Inputs (Optional) | DVI/HDMI/VGA/YpbPr/VIDEO/SDI/S-Video |
| Input resolution | XGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, compatible with custom ultra-high resolution |
| Output Signal | DVI/VGA output |
| Output resolution | 1920*1200/60HZ (compatible with standard resolution ) |
| system control software | ApplicationPro dedicated control software |
| Power | Dual power supplies 100AC~240VAC,50/60Hz, more trustable hot-swappable power supply working mode, internationally self-adaptive power |
| consumption | 12w per channel |
| working temperature | -20℃——60℃ |
| working humidity | 5-95% |
| Chassis size | 4U/6U/10U/15U standard rackmount chassis |
| Serial port | RS-232, 9 pin, D-type connector |
| Baud rate | 115200 |
| Serial port architecture | 2=TX,3=RX,5=GND |
| Ethernet control port | RJ-45 female ports, TCP/IP protocol |
| Ethernet control speed |
Self-adaptive 10M or 100M, full duplex or half duplex |
| Working hours | 7 days x 24 hours |
| Product name | Custom Made 4k 2x2 2x4 HDMI Video Wall Controller Systems For LCD Video Display Screens |
Using application show:
Custom Made 4k 2x2 2x4 HDMI Video Wall Controller Systems For LCD Video Display Screens
