Product Details:
|
| Control CMS Control: | DIMP Software | Control BS Control: | No Need To Install Any Client Software |
|---|---|---|---|
| Control Cross-platform Control: | Support Windows, IOS MACOS, Android, Linux | Power: | Dual Power Supplies 100AC~240VAC,50/60Hz, |
| Working Temperature: | "-20℃--60℃ | Product Name: | Video Wall Controller 4x4 Hdmi Video Wall Processor Video Matrix 3x3 Tv Wall Controller |
| Highlight: | 100VAC Video Wall Controller 4x4,Matrix Video Wall Controller 4x4,Matrix 3x3 TV Wall Controller |
||
Video Wall Controller 4x4 Hdmi Video Wall Processor Video Matrix 3x3 Tv Wall Controller
Description:
With this 4K Video Wall Controller you will get images almost 4 X clearer and sharper then a typical 1080p
Video Wall Controller giving you the best possible image over your 9 displays. This premium 3x3 4x4
Video Wall Controller offers a variety of input, control, and setting options that will allow you to easily create
and control almost any type of Video wall and/or Digital signage display you can think of. With all its features
such as 180 degree rotation and bezel adjustment you can create unique and eye catching Video Walls that
are sure to catch the attention of anyone who see them.
This 3x3 4k Video Wall Controller comes with built in Web Interface allowing you to easily access and control
it anywhere on your network.
Technical Parameters:
| HD digital video wall processor | |
| Description | Up to sixteen video windows per display channel (Optional) |
| Inputs (Optional) | DVI/HDMI/VGA/YpbPr/VIDEO/SDI/S-Video |
| Input resolution | XGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, compatible with custom ultra-high resolution |
| Output Signal | DVI/VGA output |
| Output resolution | 1920*1200/60HZ (compatible with standard resolution ) |
| system control software | ApplicationPro dedicated control software |
| Power | Dual power supplies 100AC~240VAC,50/60Hz, more trustable hot-swappable power supply working mode, internationally self-adaptive power |
| consumption | 12w per channel |
| working temperature | -20℃——60℃ |
| working humidity | 5-95% |
| Chassis size | 4U/6U/10U/15U standard rackmount chassis |
| Serial port | RS-232, 9 pin, D-type connector |
| Baud rate | 115200 |
| Serial port architecture | 2=TX,3=RX,5=GND |
| Ethernet control port | RJ-45 female ports, TCP/IP protocol |
| Ethernet control speed |
Self-adaptive 10M or 100M, full duplex or half duplex |
| Working hours | 7 days x 24 hours |
| Product name | Video Wall Controller 4x4 Hdmi Video Wall Processor Video Matrix 3x3 Tv Wall Controller |
Using application show:
Video Wall Controller 4x4 Hdmi Video Wall Processor Video Matrix 3x3 Tv Wall Controller
