Product Details:
|
| Chassis Size: | 1U/2U/3.5U/7U/12.5U Standard Rackmount Chassis | Serial Port: | RS-232, 9 Pin, D-type Connector |
|---|---|---|---|
| Working Humidity: | 5-95% | Working Temperature: | "-20℃--60℃ |
| Consumption: | 12w Per Channel | Product Name: | Hdmi 2x3 3x3 2x2 4k Diy Video Tv Wall Controller Kit 1x2 Video Wall Splitter |
| Highlight: | RS232 TV Wall Controller,2x2 TV Wall Controller,1x2 Video Wall Splitter |
||
Hdmi 2x3 3x3 2x2 4k Diy Video Tv Wall Controller Kit 1x2 Video Wall Splitter
Usage Description:
Hdmi 2x3 3x3 2x2 4k Diy Video Tv Wall Controller Kit 1x2 Video Wall Splitter is widely used
in KTV,hotels,bars,leisure centers,shopping malls,television stores,cinemas,
products display,media advertising,building,education and training,Brand stores,airports,subway,
Technical Parameters:
| HD digital video wall processor | |
| Description | Up to sixteen video windows per display channel (Optional) |
| Inputs (Optional) | DVI/HDMI/VGA/YpbPr/VIDEO/SDI/S-Video |
| Input resolution | XGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, compatible with custom ultra-high resolution |
| Output Signal | DVI/VGA output |
| Output resolution | 1920*1200/60HZ (compatible with standard resolution ) |
| system control software | ApplicationPro dedicated control software |
| Power | Dual power supplies 100AC~240VAC,50/60Hz, more trustable hot-swappable power supply working mode, internationally self-adaptive power |
| consumption | 12w per channel |
| working temperature | -20℃——60℃ |
| working humidity | 5-95% |
| Chassis size | 4U/6U/10U/15U standard rackmount chassis |
| Serial port | RS-232, 9 pin, D-type connector |
| Baud rate | 115200 |
| Serial port architecture | 2=TX,3=RX,5=GND |
| Ethernet control port | RJ-45 female ports, TCP/IP protocol |
| Ethernet control speed |
Self-adaptive 10M or 100M, full duplex or half duplex |
| Working hours | 7 days x 24 hours |
| Product name | Hdmi 2x3 3x3 2x2 4k Diy Video Tv Wall Controller Kit 1x2 Video Wall Splitter |
Using application show:
Hdmi 2x3 3x3 2x2 4k Diy Video Tv Wall Controller Kit 1x2 Video Wall Splitter
