Product Details:
|
| Product Name: | 3x2 2x4 2x3 HDMI Video Wall Controller With CE RoHs FCC Passed | Inputs: | 4 Channels HDMI Input Ports |
|---|---|---|---|
| Outputs: | 12 Channels HDMI Output Ports | Input Resolution: | XGA/SXGA/SXGA+/UVGA/WUXGA/1080p,etc, Compatible With Custom Ultra-high Resolution |
| Output Resolution: | 1920*1200/60HZ (compatible With Standard Resolution ) | System Control Software: | Application Pro Dedicated Control Software |
| Power: | Dual Power Supplies 100AC~240VAC,50/60Hz, More Trustable Hot-swappable Power Supply Working Mode, Internationally Self-adaptive Power | Consumption: | 12w Per Channel |
| Highlight: | FCC HDMI Video Wall Controller,3x4 HDMI Video Wall Controller,3x3 Hdmi Video Wall Processor |
||
3x2 2x4 2x3 HDMI Video Wall Controller with CE RoHs FCC passed
Product Introduction:
Advanced pure hardware structure Pure hardware architecture, internal self-core computing
mechanisms, no CPU and no OS, no blue screen and free from viruses trouble, no plug in
card processor crash, start-up time less than 5 seconds, double-backup redundant power
supply and support hot backup, able to continue to work throughout the year.
|
Model series |
With CBD |
No CBD |
|
Function description |
4channel CBD,16channel AV, 12channel VGA/DVI input, 6U case supports 12 screens arrays, compatible with ultra-high resolution 4000/(8000)x2000 Dynamic background image |
16channel AV,16channel VGA/ DVI input,6U case supports 16screens arrays |
|
Input signal(optional) |
HDMI/DVI/VGA/AV/YPbPr |
|
|
Input resolution |
1024x768~1080p,commonly used resolutions |
|
|
Output signal format |
DVI/VGA/AV/YPbPr/HDMI(DVI-HDMI converter) |
|
|
Output resolution |
Up to 1920*1200/60HZ |
|
|
System control software |
Special control software |
|
|
Power Supply |
Redundant power supply 110-220VAC, 50/60Hz |
|
|
Consumption |
12W/channel |
|
|
Working temperature |
-20°C——60°C |
|
|
Working Humidity |
5-95% |
|
|
Case specification |
1U/2U/3.5U/7U/12.5U standard rackmount chassis |
|
|
Serial Control Interface |
RS-232,9-pin female, Type-D |
|
|
Baud Rate |
115200 |
|
|
Pin configuration |
2=TX,3=RX,5=GND |
|
|
Ethernet control interface |
RJ-45 female, TCP/IP |
|
|
Ethernet control speed |
Auto 10M or 100M,Full-duplex or half-duplex |
|
|
Working time |
365*7*24hrs |
|
|
Technical specification of input/output connectors |
||
|
VGA/RGB input |
Input: 15pin HD D-Sub, female |
|
|
Sync mode: HV independent sync |
||
|
Color Depth: 32bit/pixel |
||
|
Resolution: 640*480/60HZ—1920*1200/60HZ |
||
|
Input impedance :75Ω |
||
|
Video input |
Input connector: BNC |
|
|
Detecting: full-format auto detecting |
||
|
Input impedance :75Ω |
||
|
VGA or DVI output |
Resolution:1024*768/60HZ-1920*1200/60HZ |
|
|
Color depth: 32bit/pixel |
||
|
Output impedance:75Ω |
||
|
Signals |
Connectors |
Type |
|
Composite VIDEO input |
BNC |
female |
|
VGA input |
15 pin HD D-Sub |
female |
|
VGA output |
15 pin HD D-Sub |
female |
|
DVI output |
24+5 or 24+1 standard |
female |
|
AUX RS-232 |
9-pin D-Sub |
female |
|
Main RS-232 |
9-pin D-Sub |
female |
HDMI video wall controller using application fields:
Resizing and overlapping
Windows can be sized and overlapped as required anywhere
