Product Details:
|
| Resolution Support: | 4K | Support Protocol: | HDMI2.0 |
|---|---|---|---|
| HDCP: | HDCP 2.2 | Power Supply: | Single -circuit:DC 12V/1A |
| Video Bandwidth: | 18Gbps | Storage Temperature: | -20°~60°C/-4°F~104°F |
| Audio Interface: | 3.5mm Stereo Audio Socket | Product Name: | 4K@60Hz HDMI Fiber Optic Extender |
Experience ultra-stable and long-distance 4K HDMI transmission with our HDMI 4K Optical Extender. Designed for high-performance AV applications, this HDMI extender 4K 60Hz solution supports 4K UHD@60Hz over single-mode fiber up to 10km, ensuring zero latency, high fidelity, and EMI-free signal delivery. Ideal for mission-critical scenarios such as control rooms, broadcasting, and large-scale digital signage.
This 4K HDMI optical extender is your reliable choice for HDMI over fiber needs, offering seamless integration with IR control, EDID management, and plug-and-play usability.
✅ Supports 4K@60Hz UHD resolution
✅ Up to 10km transmission over single-mode fiber
✅ Zero latency, lossless transmission
✅ EMI/RFI resistant – perfect for industrial environments
✅ Integrated IR & RS-232 passthrough
✅ HDMI 2.0 / HDCP 2.2 compliant
✅ Plug & Play design, no software required
✅ Ideal for long-distance 4K HDMI signal extension
| Video | Supported Protocol | HDMI 2.0b |
| Video Bandwidth | 18Gbps | |
| HDCP | HDCP 2.2 | |
| Interface Bandwidth | 18Gbps | |
| Color Depth | RGB4:4:4 8-bit downward compatible | |
| Video Color Space | RGB4:4:4, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0 | |
| Interface | HDMI-A interface | |
| Impedance | 100Ω | |
| Suggested Maximum HDMI Cable Input/Output Distance | Less than 10M. When the resolution is above 1920×1080@60Hz,it can reach 30M when using a cable with equalization. | |
| Audio | Audio Mode | Stereo |
| Audio Interface | 3.5mm stereo audio socket | |
| Audio Signal Type | Audio embedding and de-embedding | |
| RS232 | Interface | Phoenix Terminal |
| Signal Direction | Bidirectional Transmission | |
| Baud Rate | Default 38400bps, can be manually selected from 600-115200bps | |
| IR | IR Frequency | 38KHz |
| Optical Fiber | Optical Fiber Interface | LC Interface |
| Optical Fiber Type | Single -Mode | |
| Wavelength | TX1330/RX1270nm；TX1270nm/RX1330nm | |
| Interface Bandwidth | 10G | |
| Suggested Maximum Transmission Distance | Single-Mode Optical Fiber:10km | |
| Other | Power Supply | Single -circuit:DC 12V/1A |
| Maximum Power Consumption | Without KVM:max 4W;With KVM:max 6W | |
| Operating Temperature | 0°~40°C/32°F~104°F | |
| Humidity | 20~90% RH(No Condensation) | |
| Storage Temperature | -20°~60°C/-4°F~104°F | |
| Operating Time | 7*24 hours |
This HDMI over fiber extender is ideal for:
